Specifications
| Product Number | EGR-01000 |
| For Use In | Hardwood, Softwood |
| Threaded Insert Type | Hammer In |
| Material | Zinc-Plated Steel |
| System of Measurement | Inch |
| Thread Direction | Right Hand |
| Thread Size | 1/4"-20 |
| Thread Type | UNC |
| Thread Spacing | Coarse |
| Thread Fit | Class 2B |
| Installed Length | 0.36" |
Barrel |
|
| Diameter | 0.305" |
| For Min. Material Thickness | 5/16" |
Flange |
|
| Diameter | 3/4" |
| Thickness | 0.047" |
| Number of Prongs | 4 |
| Prong Length | 15/64" |
| Drill Bit Size | 5/16" |
| For Maximum Hole Diameter | 5/16" |
| End Type | Open |
| Tensile Strength | 40,000 psi |
| REACH | REACH (EC 1907/2006) (07/16/2019, 201 SVHC) Compliant |
| RoHS | RoHS 3 (2015/863/EU) compliant |
