Specifications
| Product Number | EE5-03000 |
| Material | Steel |
| Finish | Zinc Plated |
| Fastener Strength Grade/Class | Grade 5 |
| Thread Size | 3/8"-16 |
| Thread Type | UNC |
| Thread Spacing | Coarse |
| Thread Fit | Class 2B |
| Thread Direction | Right Hand |
| Width | 9/16" |
| Height | 11/32" |
Flange |
|
| Diameter | 3/4" |
| Thickness | 0.04" |
| Drive Style | External Hex |
| Nut Type | Flange, Locknut |
| Hex Nut Profile | Standard |
| Locking Type | Serrations |
| System of Measurement | Inch |
| RoHS | Compliant |
