Welding Hook jaune Painted Alloy Steel 3-1/4"

Welding Hook jaune Painted Alloy Steel 3-1/4"

20.90 $ CAD
20.90 $ CAD
Sale Sold out
Shipping calculated at checkout.
Title
Download

This hook has a weight load limit of 4400 lbs. It is made of jaune painted alloy stee and thus provide medium resistance to corrosion in both dry and wet environments. The hooks have a diameter of 3-1/4. The hooks are grade 80.

View full details

Specifications
Product Number CRO-02080-W-51
Material and/or Plating Yellow Painted Alloy Steel
System of Measurement Imperial

Product Specification
Type Welding
Usable For Leverage Yes
Width (F) 1-11/32"
Opening Width (P) 63/64"
Outer Width (L) 3-45/64"
Overall Length (W) 3-5/32"
Bottom Thickness (H) 15/16"
Bottom Min. Width (T) 25/32"

Strength Specifications
Work Load Limit 4400 Lbs
Security Factor 4 : 1
Ultimate Weight Load 17600 Lbs
