Specifications
Specifications |
|
|---|---|
| Nominal Diameter | M5 |
| Length | 12 mm |
| Thread Pitch | 0.8 mm |
| Material | Acier inoxydable AISI 304 |
| Finition | Black Oxide |
| Système de mesure | Métrique |
Thread Specifications |
|
| Threading | Fully Threaded |
| Type | Metric | Coarse |
| Direction | Right Hand |
| Size | M5 × 0.8 |
| Shank Length | 12 mm |
| Fit | Class 6g |
Head Specifications |
|
| Type | Flat Large Mince |
| Profile | Standard |
| Diameter | 9 mm |
| Height | 1.5 mm |
| Drive Style | Hex Socket / Standard |
Neck Specifications |
|
| Form | Cylindrique |
Strength Specifications |
|
| Grade/Class | A2-70 |
| Tensile Strength | 700 MPa |
| Shear Strength | 450 MPa |
| Classification | ISO 3506 |
