Specifications
| Product Number | VPSC-00812 |
| Head Type | Socket |
| Socket Head Profile | Standard |
| Drive Style | Hex |
| System of Measurement | Inch |
| Thread Direction | Right Hand |
| Thread Size | 10-24 |
| Screw Size Decimal Equivalent | 0.19" |
| Thread Type | UNC |
| Thread Fit | Class 3A |
| Length | 1-1/4" |
| Threading | Partially Threaded |
| Min. Thread Length | 7/8" |
| Thread Spacing | Coarse |
Head |
|
| Diameter | 5/16" |
| Height | 0.19" |
| Drive Size | 5/32" |
| Tensile Strength | 70,000 psi |
| Hardness | Rockwell B70 |
| Material | 18-8 Stainless Steel |
| RoHS 3 (2015/863/EU) | Compliant |
