Specifications
| Product Number | VPCTFI-03007 |
| Thread Size | 3/8"-24 |
| Length | 3/4" |
| Threading | Fully Threaded |
| Thread Spacing | Fine |
Head |
|
| Diameter | 9/16" |
| Height | 0.188" |
| Drive Size | 3/16" |
| Material | Black-Oxide Alloy Steel |
| Hardness | Rockwell C39 |
| Tensile Strength | 140,000 psi |
| Screw Size Decimal Equivalent | 0.375" |
| Thread Type | UNF |
| Thread Fit | Class 3A |
| Thread Direction | Right Hand |
| Head Type | Socket |
| Socket Head Profile | Low |
| Drive Style | Hex |
| Specifications Met | ASTM A574 |
| System of Measurement | Inch |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | REACH (EC 1907/2006) (01/16/2020, 205 SVHC) Compliant |
| Country of Origin | Taiwan |
