Welding Hook jaune Painted Alloy Steel 6-1/8"

Welding Hook jaune Painted Alloy Steel 6-1/8"

$52.00
$52.00
Sale Sold out
Shipping calculated at checkout.
Title
Download

This hook has a weight load limit of 11000 lbs. It is made of jaune painted alloy stee and thus provide medium resistance to corrosion in both dry and wet environments. The hooks have a diameter of 6-1/8. The hooks are grade 80.

View full details

Specifications
Product Number CRO-05080-W-51
Material and/or Plating Yellow Painted Alloy Steel
System of Measurement Imperial

Product Specification
Type Welding
Usable For Leverage Yes
Width (F) 1-47/64"
Opening Width (P) 1-11/32"
Outer Width (L) 5-13/64"
Overall Length (W) 6-7/64"
Bottom Thickness (H) 1-11/16"
Bottom Min. Width (T) 1-7/64"

Strength Specifications
Work Load Limit 11000 Lbs
Security Factor 4 : 1
Ultimate Weight Load 44000 Lbs

Specifications
Product Number CRO-05080-W-51
Material and/or Plating Yellow Painted Alloy Steel
System of Measurement Imperial

Product Specification
Type Welding
Usable For Leverage Yes
Width (F) 1-47/64"
Opening Width (P) 1-11/32"
Outer Width (L) 5-13/64"
Overall Length (W) 6-7/64"
Bottom Thickness (H) 1-11/16"
Bottom Min. Width (T) 1-7/64"

Strength Specifications
Work Load Limit 11000 Lbs
Security Factor 4 : 1
Ultimate Weight Load 44000 Lbs
